Series and parallel circuits
GCSE Physics · Electricity
1. Key quantities and equations
- Current (I): the rate of flow of charge, measured in amperes (A).
- Potential difference (V): measured in volts (V).
- Resistance (R): measured in ohms (Ω).
- Charge flow (Q): measured in coulombs (C), with time (t) in seconds (s).
- Power (P): measured in watts (W). Energy transferred (E) is measured in joules (J).
- Charge: Q = It, charge flow equals current × time.
- Ohm's law: V = IR, potential difference equals current × resistance.
- Power: P = IV, which can also be written as P = I²R.
- Energy: E = Pt, energy transferred equals power × time.
Current is charge per second and power is energy per second, so the equations follow from these definitions.
Check yourself: A 0.50 A current flows through the 8.0 Ω resistor in worked example 1. Calculate the potential difference across it, showing your working.
2. Series circuits
- Single loop: components are connected one after another, giving only one path for charge.
- Current: the same at every point in the loop.
- Potential difference: the supply potential difference is shared between components.
- Total resistance: the sum of the individual resistances, R total = R1 + R2.
With only one path, all the charge must pass through every component, so the current is the same throughout.
Worked example:
A 6.0 V battery is connected in series with a 4.0 Ω resistor and an 8.0 Ω resistor.
- Total resistance: 4.0 + 8.0 = 12 Ω
- Current: I = V ÷ R = 6.0 ÷ 12 = 0.50 A, the same through both resistors
- Potential difference across 4.0 Ω: V = IR = 0.50 × 4.0 = 2.0 V
- Potential difference across 8.0 Ω: V = IR = 0.50 × 8.0 = 4.0 V
- Power in 4.0 Ω: P = IV = 0.50 × 2.0 = 1.0 W
- Same power using P = I²R: 0.50² × 4.0 = 1.0 W
- Energy in 60 s: E = Pt = 1.0 × 60 = 60 J
- Charge in 60 s: Q = It = 0.50 × 60 = 30 C
Check: 2.0 V + 4.0 V = 6.0 V, the supply potential difference.
Exam trap: current is not used up by a component. It is the same before and after it in series.
Check yourself: A 12 V supply is connected in series with a 2.0 Ω resistor and a 4.0 Ω resistor. Calculate the current in the circuit, showing your working.
3. Parallel circuits
- Separate branches: components give the charge more than one path.
- Potential difference: the same across each branch as the supply.
- Total current: the sum of the currents through the separate branches.
- Total resistance: less than the smaller of the two resistors.
Each extra branch gives charge another route, so more current flows from the supply. Total resistance is V ÷ I, so it falls.
Worked example:
A 6.0 V battery is connected to two 6.0 Ω resistors in parallel.
- Each resistor has 6.0 V across it.
- Current in each branch: I = V ÷ R = 6.0 ÷ 6.0 = 1.0 A
- Total current: 1.0 + 1.0 = 2.0 A
- Total resistance: R = V ÷ I = 6.0 ÷ 2.0 = 3.0 Ω
Check: 3.0 Ω is less than 6.0 Ω, as expected for parallel resistors.
Your question: "Why does adding a resistor in parallel lower the total resistance?" The new branch gives charge another path, so more current flows in total. The supply potential difference stays the same, so V ÷ I is lower.
Exam trap: do not add parallel resistances like series ones. Two 6.0 Ω resistors in parallel give 3.0 Ω, not 12 Ω.
Check yourself: A 3.0 Ω resistor and a 6.0 Ω resistor are connected in parallel. Without calculating the total, explain why their total resistance must be less than 3.0 Ω.
4. Series and parallel compared
| Feature |
Series |
Parallel |
| Current |
The same everywhere |
Splits between branches; total is the sum of branch currents |
| Potential difference |
Shared between components |
The same across each branch |
| Total resistance |
The sum of the resistances |
Less than the smallest single resistance |
| If one lamp breaks |
The current stops, so every lamp goes out |
The other branches still work |
A single loop has one path, so one break stops the current everywhere.
Check yourself: Explain why the lights in a house are connected in parallel rather than in series.
5. Common mistakes
- Current used up: the charge transfers energy to a component, but the current stays the same.
- Series rule in parallel: parallel resistances are not added like series ones.
- Wrong units: in Q = It and E = Pt, time must be in seconds, not minutes.
Current is a rate of charge flow, so it cannot be used up. Energy formulae only give joules when power is in watts and time is in seconds.
Check yourself: Explain why time must be in seconds when you use E = Pt to get an answer in joules.
Exam checklist
- Current is the same everywhere in series but splits between branches in parallel.
- In parallel, the potential difference across each branch equals the supply potential difference.
- Total parallel resistance is found using V ÷ I, not by simple addition.
- Convert minutes to seconds before using Q = It or E = Pt.
- In Explain answers, complete the chain: more branches, more current, lower total resistance.
- Describe parallel breaks as: other branches keep working.
One-minute recap
Series circuits have one path, so the current is the same everywhere. The supply potential difference is shared between components, and resistances add. Parallel circuits have several branches, each with the full supply potential difference. Total current is the sum of branch currents, so total resistance is less than the smallest resistor. Use V = IR, P = IV, E = Pt and Q = It with time in seconds.
Check-yourself answers
- V = IR = 0.50 × 8.0 = 4.0 V. Ohm's law gives the potential difference from the current through the resistor and its resistance.
- Total resistance is 2.0 + 4.0 = 6.0 Ω, so I = V ÷ R = 12 ÷ 6.0 = 2.0 A. The current is the same everywhere in a series loop.
- Adding a parallel branch gives charge another path, so the total resistance is less than the smallest single resistor, here 3.0 Ω.
- Each parallel lamp has the full supply potential difference across it, and each has its own branch. If one lamp breaks, the other branches still have a path, so they keep working.
- Power is in watts (joules per second), so time must be in seconds for energy to come out in joules.
